Specifications
| Details |
| Product code |
RBwsAP-5Hac2nD |
| Architecture |
MIPSBE |
| CPU |
QCA9531 |
| CPU core count |
1 |
| CPU nominal frequency |
650 MHz |
| Switch chip model |
QCA9531 |
| Dimensions |
112 x 126 x 30 mm |
| RouterOS license |
4 |
| Operating System |
RouterOS |
| Size of RAM |
64 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 100’000 hours at 25C |
| Tested ambient temperature |
-40°C to 60°C |
Wireless capabilities
| Details |
| Wireless 2.4 GHz Max data rate |
300 Mbit/s |
| Wireless 2.4 GHz number of chains |
2 |
| Wireless 2.4 GHz standards |
802.11b/g/n |
| Antenna gain dBi for 2.4 GHz |
1.5 |
| Wireless 2.4 GHz chip model |
QCA9531 |
| Wireless 2.4 GHz generation |
Wi-Fi 4 |
| Wireless 5 GHz Max data rate |
433 Mbit/s |
| Wireless 5 GHz number of chains |
1 |
| Wireless 5 GHz standards |
802.11a/n/ac |
| Antenna gain dBi for 5 GHz |
3 |
| Wireless 5 GHz chip model |
QCA-9887 |
| Wireless 5 GHz generation |
Wi-Fi 5 |
| WiFi speed |
AC750 |
Ethernet
| Details |
| 10/100 Ethernet ports |
3 |
Peripherals
| Details |
| Number of USB ports |
1 |
| USB Power Reset |
Yes |
| USB slot type |
USB type A |
| Max USB current (A) |
0.5 |
Powering
| Details |
| Number of DC inputs |
1 (PoE-IN) |
| Max power consumption |
20 W |
| Max power consumption without attachments |
6 W |
| Cooling type |
Passive |
| PoE in |
802.3af/at |
| PoE in input Voltage |
18-57 V |
PoE-out
| Details |
| PoE-out ports |
Ether3 |
| PoE out |
Passive PoE |
| Max out per port output (input 18-30 V) |
420 mA |
| Max out per port output (input 30-57 V) |
420 mA |
| Max total out (A) |
420 mA |
Certification & Approvals
| Details |
| Certification |
CE, FCC, IC, EAC, ROHS |
| IP |
IP20 |
Other
Wireless specifications
| 2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
| 1MBit/s |
22 |
-96 |
| 11MBit/s |
22 |
-89 |
| 6MBit/s |
20 |
-93 |
| 54MBit/s |
18 |
-74 |
| MCS0 |
20 |
-93 |
| MCS7 |
16 |
-71 |
| 5 GHz |
Transmit (dBm) |
Receive Sensitivity |
| 6MBit/s |
23 |
-93 |
| 54MBit/s |
20 |
-75 |
| MCS0 |
23 |
-93 |
| MCS7 |
19 |
-71 |
| MCS9 |
16 |
-63 |
