Specifications
| Main Input Voltage | 120 V |
| Main Output Voltage | 120 V |
| Kw Rating | 330 W |
| Rated power in VA | 550 VA |
| Input Connection Type | NEMA 5-15P |
| output connection type | 4 NEMA 5-15R 4 NEMA 5-15R surge |
| Cable length | 5 ft (1.52 m) |
| Number of cables | 1 |
| Battery Type | Lead-Acid battery |
| Provided equipment | User Manual USB cable |
| General | |
| Number of power module free slots | 0 |
| Number of power module filled slots | 0 |
| Redundant | No |
| Physical | |
| color | Black |
| Height | 3.46 in (8.8 cm) |
| Width | 7.09 in (18 cm) |
| Depth | 11.89 in (30.2 cm) |
| Net Weight | 12.13 lb(US) (5.5 kg) |
| Mounting Location | Front |
| Mounting preference | No preference |
| Mounting Mode | Not rack-mountable |
| Two post mountable | 0 |
| USB compatible | Yes |
| Input | |
| Input Frequency | 50/60 Hz +/- 3 Hz auto-sensing |
| Efficiency at full load | 88…139 V |
| Output | |
| Max Configurable Power (Watts) | 330 W |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| Topology | Standby |
| Waveform Type | Stepped approximation to a sinewave |
| Maximum configurable power in VA | 550 VA |
| Transfer Time | 8ms typical : 12ms maximum |
| Conformance | |
| Product Certifications | California (CEC) Battery Charger ENERGY STAR V2.0 (USA) NOM TÜV-C |
| Equipment protection policy | Lifetime : $75000 |
| Environmental | |
| Ambient Air Temperature for Operation | 32…104 °F (0…40 °C) |
| Relative Humidity | 5…95 % |
| Operating altitude | 0…10000 ft |
| Ambient Air Temperature for Storage | 5…113 °F (-15…45 °C) |
| Storage Relative Humidity | 5…95 % |
| Storage altitude | 0…50000 ft (0.00…15240.00 m) |
| Acoustic level | 45 dBA |
| Heat dissipation | 16 Btu/h |
