Specifications
Details:
- Product code RB750Gr3
- Architecture MMIPS
- CPU MT7621A
- CPU core count 2
- CPU nominal frequency 880 MHz
- CPU Threads count 4
- Switch chip model MT7621A
- Dimensions 113x89x28mm
- RouterOS license 4
- Operating System RouterOS
- Size of RAM 256 MB
- Storage size 16 MB
- Storage type FLASH
- MTBF Approximately 100’000 hours at 25C
- Tested ambient temperature -40°C to 60°C
- IPsec hardware acceleration Yes
Powering
Details:
- Number of DC inputs 2 (DC jack, PoE-IN)
- DC jack input Voltage 8-30 V
- Max power consumption 10 W
- Max power consumption without attachments 5 W
- Cooling type Passive
- PoE in Passive PoE
- PoE in input Voltage 8-30 V
Ethernet
Details:
- 10/100/1000 Ethernet ports 5
Peripherals
Details:
- Memory card type microSD
- Memory Cards 1
- Number of USB ports 1
- USB Power Reset Yes
- USB slot type USB type A
- Max USB current (A) 1
Other
Details:
- PCB temperature monitor Yes
- Voltage Monitor Yes
- Mode button Yes
- Beeper Yes
Certification & Approvals
Details:
- Certification CE, EAC, ROHS
- IP IP20
