Specifications
Details:
- Product code RB750P-PBr2
- Architecture MIPSBE
- CPU QCA9533
- CPU core count 1
- CPU nominal frequency 650 MHz
- Switch chip model QCA9533
- Dimensions 125x178x48mm
- RouterOS license 4
- Operating System RouterOS
- Size of RAM 64 MB
- Storage size 16 MB
- Storage type FLASH
- MTBF Approximately 100’000 hours at 25C
- Tested ambient temperature -40°C to 70°C
Powering
Details:
- Number of DC inputs 2 (DC jack, PoE-IN)
- DC jack input Voltage 8-30 V
- Max power consumption 50 W
- Max power consumption without attachments 2 W
- Cooling type Passive
- PoE in Passive PoE
- PoE in input Voltage 8-30 V
PoE-out
Details:
- PoE-out ports Ether2-Ether5
- PoE out Passive PoE
- Max out per port output (input 18-30 V) 1 A
- Max total out (A) 2 A
Ethernet
Details:
- 10/100 Ethernet ports 5
Other
Details:
- Current Monitor Yes
- PCB temperature monitor Yes
- Voltage Monitor Yes
Certification & Approvals
Details:
- Certification CE, EAC, ROHS
- IP 20
- Included parts
