| Part No. | R6615 |
| Manufacturer | Dell Technologies |
| End of Life? | No |
| Height | 86.8mm |
| Width | 434mm |
| Depth | 657.25mm |
| Weight [Kg] | 16.75 |
| CPU Socket(s) | One 2nd or 3rd Generation AMD EPYC Processor with up to 64 cores |
| Compatible CPU(s) | 7H12, 7742, 7702, 7702P, 7662, 7642, 7552, 7542, 7532, 75002, 7502P, 7452, 7f72, 7402, 7402P, 7352, 7F52, 7302, 7302P, 7282, 7272, 7F32, 7262, 7252, 723P , 7713P, 7543P , 7443P, 7313P, 7763,7713, 7663,7643, 7543, 7513, 7453, 7443, 7413, 7343, 7313, 75F3, 74F3, 73F3, 72F3 |
| Max # Thread(s) | Up to 128 Threads per CPU |
| Memory Slot(s) | DDR4: Up to 16 x DDR4 |
| Memory Capacity | RDIMM (1TB), LRDIMM (2TB), bandwidth up to 3200 MT/S |
| Drive Bays | Front Bays Up to 4x 3.5” Hot Plug SAS/SATA HDD Up to 10x 2.5” Hot Plug SAS/SATA/NVMe Up to 8x 2.5” Hot plug SAS/SATA Hot Pluggable BOSS card (2x M.2) on Rear |
| SATA Controller | Chipset SATA/SW RAID: S150 |
| RAID Options | HW RAID: PERC 9/10 – HBA330, H330, H730P, H740P, H840, 12G SAS HBA |
| Supported OS | Canonical® Ubuntu® Server LTS Citrix® HypervisorTM Microsoft® Windows Server® with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi® |
| USB Port(s) | 1 x USB 2.0 2 x USB 3.0 |
| PCI Slot(s) | Up to 2: 1 x Gen3 slot (1 x16) 1 x Gen4 slot (1 x16) |
| Serial Ports | 1 x Serial |
| LAN Socket(s) | Networking Options (NDC) 2 x 1GbE 2 x 10GbE BT 2 x 10GbE SFP+ 2 x 25GbE SFP28 |
