| General | |
| Type | Server |
| Bundled Services | 3 Years Basic Onsite |
| Product Form Factor | Rack-mountable – 2U |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 8 |
| Colour | Black |
| Processor / Chipset | |
| CPU | Intel Xeon Silver 4314 |
| Clock Speed | 2.4 GHz |
| Max Turbo Speed | 3.4 GHz |
| Number of Cores | 16-core |
| CPU Qty | 1 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Intel Turbo Boost Technology 2 |
| CPU Socket | FCLGA4189 Socket |
| Cache Memory | |
| Installed Size | 24 MB |
| Cache Per Processor | 24 MB |
| RAM | |
| Installed Size | 32 GB / 1 TB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 2667 MHz |
| Rated Memory Speed | 3200 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 16 (Total) / 15 (empty) |
| Features | Registered, dual rank |
| Configuration Features | 1 x 32 GB |
| Hard Drive | |
| Type | SSD – hot-swap – 2.5″ |
| Capacity | 1 x 480 GB |
| Interface Type | SATA 6Gb/s |
| Features | 1 DWPD, Read Intensive |
| Storage Controller | |
| Type | 1 x RAID |
| Storage Controller Name | PERC H755 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Matrox G200 |
| Video Memory | 16 MB |
| Video Interfaces | VGA |
| Networking | |
| Ethernet Ports | 2 x 10 Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM57412 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Remote Management Controller | Integrated Dell Remote Access Controller 9 Enterprise 15G (iDRAC9 15G) |
| Compliant Standards | OCP 3.0 |
| Expansion / Connectivity | |
| Bays | 8 (total) / 7 (free) x hot-swap 3.5″ |
| Slots | 1 (total) / 1 (free) x PCIe x16 – half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe x4 |
| Interfaces | 2 x LAN (10Gigabit Ethernet) (SFP+) ¦ 1 x USB 3.0 ¦ 2 x USB 2.0 (1 front, 1 rear) ¦ 1 x management – micro-USB (1 in front) (iDRAC Direct port) ¦ 2 x VGA (1 front, 1 rear) |
| Miscellaneous | |
| Included Accessories | Bezel, ReadyRails sliding rails without cable management arm |
| Pricing Type | Build To Plan (BTP) |
| Power | |
| Device Type | Power supply – hot-plug |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Provided | 800 Watt |
| Operating System / Software | |
| OS Provided | No operating system |
| Dimensions & Weight | |
| Width | 48.2 cm |
| Height | 8.68 cm |
| Weight | 24.8 kg |
