Memory24 DIMM slots for HPE DDR4 SmartMemory, maximum 4.0 TB per processor
NetworkOptional OCP 3.0 or PCIe NICs up to 200 Gb/s
StorageStandard 24 LFF SAS/SATA/SSD and 48 SFF SAS/SATA/SSD CTO models, optional storage upgrade 4 LFF SAS/SATA/SSD Cage 3, 8 SFF SAS/SATA/NVMe U.3 Tri-mode Cage 3, 2 SFF SAS/SATA/NVMe U.3 Tri-mode Cage 4, or 2 SFF SAS/SATA/NVMe U.3 Tri-mode Cage 5
PowerUp to 2 power supplies, choice of 800W or 1600W hot-plug and redundant
Form Factor2U Rack
Warranty3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support
CPUIntel® Xeon® Scalable 8300 series, Intel® Xeon® Scalable 6300 series, Intel® Xeon® Scalable 5300 series, Intel® Xeon® Scalable 4300 series
Memory protection featuresHPE Advanced Memory Error Detection Technology, including Fast Fault Tolerance (selected memory options)
Boot capabilitiesOptional HPE NS204i-p x2 Lanes NVMe PCIe3 x8 OS Boot Device or HPE Universal SATA 6G AIC HHHL M.2 SSD Enablement Kit
System configuration(s)Front 24 LFF model supports optional 4 LFF Cage 3 or 8 SFF cage3, and front 48 SFF model supports optional 8 SFF Cage 3. The optional Cage 3 cannot be configured with CPU higher than 165W or Intel® Optane™ Persistent Memory. The 2 SFF Cage 4 and 2 SFF Cage 5 are available for both CTO models.
Management featuresIncludes HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), and HPE InfoSight (with the free HPE iLO Amplifier Pack installed); Optional HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced
Compatible operating systemsOperating systems and virtualization solutions for HPE servers from Microsoft, Red Hat, SUSE, Ubuntu, VMware, and more. Additional information at: https://www.hpe.com/us/en/servers/server-operating-systems.html
Accelerator type supportedNVIDIA T4 16GB Computational Accelerator for HPE (planned for late 2021)
Weight41.06 lb (empty), 106.61 lb (fully-loaded)
Weight18.62 kg (empty), 48.35 kg (fully-loaded)
Minimum dimensions ( H x W x D)3.44 x 17.63 x 32.99 in (dimensions without bezel)
Minimum dimensions ( H x W x D)87.5 x 448.0 x 837.9 mm (dimensions without bezel)
Intel®, Xeon®, and Optane™ are trademarks or registered trademarks of Intel Corporation in the U.S. and other countries. Qumulo is a registered trademark of Qumulo, Inc. in the U.S. and other countries. Cohesity is a registered trademark of Cohesity, Inc. in the U.S. and other countries.
