Specifications
Details |
Product code |
RBwAPG-5HacD2HnD-BE |
Architecture |
ARM 32bit |
CPU |
IPQ-4018 |
CPU core count |
4 |
CPU nominal frequency |
488-896 (auto) MHz |
Switch chip model |
IPQ-4018 |
Dimensions |
185 x 85 x 30 mm |
RouterOS license |
4 |
Operating System |
RouterOS |
Size of RAM |
128 MB |
Storage size |
16 MB |
Storage type |
FLASH |
MTBF |
Approximately 100’000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
IPsec hardware acceleration |
Yes |
Wireless capabilities
Details |
Wireless 2.4 GHz Max data rate |
300 Mbit/s |
Wireless 2.4 GHz number of chains |
2 |
Wireless 2.4 GHz standards |
802.11b/g/n |
Antenna gain dBi for 2.4 GHz |
2.5 |
Wireless 2.4 GHz chip model |
IPQ-4018 |
Wireless 2.4 GHz generation |
Wi-Fi 4 |
Wireless 5 GHz Max data rate |
867 Mbit/s |
Wireless 5 GHz number of chains |
2 |
Wireless 5 GHz standards |
802.11a/n/ac |
Antenna gain dBi for 5 GHz |
2.5 |
Wireless 5 GHz chip model |
IPQ-4018 |
Wireless 5 GHz generation |
Wi-Fi 5 |
WiFi speed |
AC1200 |
Ethernet
Details |
10/100/1000 Ethernet ports |
2 |
Powering
Details |
Number of DC inputs |
2 (DC jack, PoE-IN) |
DC jack input Voltage |
10-57 V |
Max power consumption |
10 W |
Max power consumption without attachments |
10 W |
Cooling type |
Passive |
PoE in |
802.3af/at |
PoE in input Voltage |
18-57 V |
Certification & Approvals
Details |
Certification |
CE, FCC, IC, EAC, ROHS |
IP |
IP54 |
Other
Details |
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Wireless specifications
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
1MBit/s |
25 |
-100 |
11MBit/s |
25 |
-94 |
6MBit/s |
25 |
-96 |
54MBit/s |
19 |
-78 |
MCS0 |
25 |
-96 |
MCS7 |
18 |
-73 |
5 GHz |
Transmit (dBm) |
Receive Sensitivity |
6MBit/s |
24 |
-96 |
54MBit/s |
20 |
-80 |
MCS0 |
24 |
-96 |
MCS7 |
19 |
-75 |
MCS9 |
17 |
-70 |
