Անխափան սնուցման աղբյուր APC Back-UPS ES 550VA, 120V, 8 NEMA outlets (4 surge)

  • Main Input Voltage 120 V
  • Main Output Voltage 120 V
  • Kw Rating 330 W
  • Rated power in VA 550 VA
  • Input Connection Type NEMA 5-15P
  • Output connection type 4 NEMA 5-15R 4 NEMA 5-15R surge

AMD

Request a quote
Availability: In Stock
SKU:BE550G

Specifications

Main Input Voltage 120 V
Main Output Voltage 120 V
Kw Rating 330 W
Rated power in VA 550 VA
Input Connection Type NEMA 5-15P
output connection type 4 NEMA 5-15R
4 NEMA 5-15R surge
Cable length 5 ft (1.52 m)
Number of cables 1
Battery Type Lead-Acid battery
Provided equipment User Manual
USB cable



General
Number of power module free slots 0
Number of power module filled slots 0
Redundant No



Physical
color Black
Height 3.46 in (8.8 cm)
Width 7.09 in (18 cm)
Depth 11.89 in (30.2 cm)
Net Weight 12.13 lb(US) (5.5 kg)
Mounting Location Front
Mounting preference No preference
Mounting Mode Not rack-mountable
Two post mountable 0
USB compatible Yes



Input
Input Frequency 50/60 Hz +/- 3 Hz auto-sensing
Efficiency at full load 88…139 V



Output
Max Configurable Power (Watts) 330 W
Output frequency 50/60 Hz +/- 3 Hz sync to mains
Topology Standby
Waveform Type Stepped approximation to a sinewave
Maximum configurable power in VA 550 VA
Transfer Time 8ms typical : 12ms maximum



Conformance
Product Certifications California (CEC) Battery Charger
ENERGY STAR V2.0 (USA)
NOM
TÜV-C
Equipment protection policy Lifetime : $75000



Environmental
Ambient Air Temperature for Operation 32…104 °F (0…40 °C)
Relative Humidity 5…95 %
Operating altitude 0…10000 ft
Ambient Air Temperature for Storage 5…113 °F (-15…45 °C)
Storage Relative Humidity 5…95 %
Storage altitude 0…50000 ft (0.00…15240.00 m)
Acoustic level 45 dBA
Heat dissipation 16 Btu/h
